Client Industry
Target Products
Plastic Raw Material
500ml (portable/small pack), 1L (standard household size), 2L (refill/economy pack).
HDPE/PP extrusion blow molding machine equipped with a high-shear screw and high-efficiency plasticizing system to effectively prevent thermal degradation and ensure stable material flow.
Two-cavity mold featuring rapidly interchangeable core and cavity components designed for the three capacity specifications; equipped with a dedicated cooling system to precisely control HDPE shrinkage (1.5%–3%) and ensure dimensional consistency.
Total daily line capacity exceeds 24,000 bottles; uniform wall thickness with no thin spots; excellent bottle-mouth sealing; smooth surface finish free of parting-line burrs; fully meets requirements for high-speed integration with filling lines and end-consumer usability.
Client Industry
Target Products
Plastic Raw Material
5L (small-capacity packaging for fine chemicals), 10L (medium-capacity packaging for solvents and additives), 25L (standard large industrial drums and bulk procurement packaging).
Large‑scale extrusion blow molding machine with accumulator‑head die and advanced Wall Thickness Control (WTC) system. It enables real‑time axial parison wall‑thickness adjustment for different drum sections per strength requirements. High‑torque hydraulic drive on main unit guarantees adequate clamping force.
Single-cavity, thick-walled mold made of high-hardness mold steel to withstand high clamping forces and long-term production wear; equipped with a parison thickness control ring compatible with the WTC system; features targeted wall thickness reinforcement at critical points subject to drop impact and stacking loads.
Individual finished product weight remains stable within ±1.5% of the nominal value; uniform wall thickness distribution across the drum body; excellent stacking load-bearing performance; all units passed 1.2-meter drop tests and 24-hour airtightness tests; fully compliant with UN certification standards for chemical storage and transport as well as export packaging requirements.
